LDE-660 Deep Red Phosphor
Integrated Solution
LDE-660 Custom Formulation · Crop-Specific Light Recipes · Multi-Scenario Adaptation · Full-Process Technical Support. Addressing core plant lighting requirements with 665nm optimal photosynthetic wavelength.
Plant Lighting Core Pain Points
Targeted solutions for key technical challenges in plant lighting
Spectrum Mismatch
Ordinary light sources lack critical photosynthetic wavelengths, resulting in low efficiency and slow growth
Poor Stability
Continuous operation causes spectrum drift and light decay, affecting growth consistency
High Energy Cost
Low light utilization increases cultivation costs significantly
Process Compatibility
Must work with SMD, COB, high-power packaging while balancing flowability and stability
Weak Crop Specificity
Different crops need different spectrums; generic solutions fail customization needs
LDE-660 Deep Red Phosphor
665nm peak wavelength precisely matches Chlorophyll a absorption peak
Nitride-Based Deep Red Phosphor
112nm ultra-wide FWHM covers 600-700nm critical photosynthetic range. Nitride matrix ensures excellent thermal/humidity stability for 12-16h/day continuous greenhouse operation.
| Parameter | Specification | Significance |
|---|---|---|
| Peak Wavelength | 665±1nm | Matches Chlorophyll a absorption peak |
| FWHM | 112nm | Covers 600-700nm critical range |
| Particle Size D50 | 13μm | Balances flowability and stability |
| Relative Brightness | ≥100% | Ensures light output performance |
| 1000h Light Decay | <3% | Long-term stable operation |
LDE-660 uses nitride matrix with excellent thermal/humidity stability, supporting 12-16h/day continuous operation in high-humidity greenhouses (≥95%RH) with <15% light decay over 5 years. The 665nm peak precisely targets Chlorophyll a, while 112nm FWHM extends to Chlorophyll b region for maximum photosynthetic efficiency.
Multi-Scenario Solutions
Customized phosphor combinations for different cultivation scenarios
Vertical Farm
Multi-layer Rack / All-weather
Greenhouse Agriculture
Large-area Supplemental Lighting
Home Gardening
Desktop / Balcony Grow Lights
Scientific Research
Physiology Research / Breeding
Crop-Specific Light Recipes
Precise formulations for different crops and growth stages
Optimized Light Formulas
Tailored red-blue ratios for maximum growth efficiency
| Crop Type | Stage | Light Recipe | Effect |
|---|---|---|---|
| Leafy Vegetables | Full Cycle | 60-70% + 20-30% + White | 7-10 days shorter cycle |
| Fruiting Vegetables | Vegetative | 50-60% + 30-40% + White | Robust plants |
| Fruiting Vegetables | Flowering | 55-65% + 15-25% + Far Red | Higher yield |
| Flowering Plants | Bloom | 50-60% + 20% + Far Red | Extended flowering |
| Seedlings | Nursery | 50-60% + 30-40% + White | 30% better survival |
Pair LDE-660 with 450-460nm blue chips. Leafy vegetables: Red:Blue = 3:1~4:1. Fruiting vegetables (flowering): 5:1~6:1. Each batch includes spectrum reports with ±0.003 color coordinate precision.
Business Value Delivery
Significant economic benefits for growers and manufacturers
Improved Cultivation
Growth cycle shortened 10-20%, yield increased 20-30%, nutrients improved 15-25%
Cost Savings
Light utilization up 40%, energy down 30%, fixture life extended to 5 years
Compliance Ready
RoHS compliant, no harmful spectrum, adapts to facility agriculture and home use requirements
Experience Our Quality Firsthand
Request a free phosphor sample kit to test in your production line. Evaluate performance, processing compatibility, and quality before committing.
Full-Cycle Technical Support
One-stop service from light recipe design to cultivation tracking
Custom Light Recipes
Optimize red-blue ratios for your specific crops and goals
Sample Testing
50-100g samples for preliminary validation
Process Guidance
Full parameters for mixing, dispensing, curing
Batch Guarantee
Spectrum reports with ≤±0.003 color deviation
Certification & Compliance
Multiple authoritative certifications
LDE-660 complies with RoHS standards with no harmful spectrum output. Each batch undergoes rigorous spectrum testing, particle size analysis, and thermal stability verification. Color coordinate batch deviation controlled within ±0.003 for large-scale production consistency.
Get Your Plant Lighting Solution
Contact us for free consultation and samples
Free Consultation
Expert guidance on phosphor selection and light recipes
Custom Recipes
Tailored red-blue ratios for your specific crops
Fast Samples
50-100g samples shipped within 3 business days
Full Support
Process guidance, batch guarantee, cultivation tracking
